Stable Work with Two Wide Belts
According to the type of roughage such as grass, hay, and straw , roll bale production is possible from softcore to high density!
Bale size: D70~115cm X W100cm Bale density adjustable to 7 levels
Control Box
The control box provides easy access to settings such as bale diameter, packing density, number of net windings, and automatic net running. Bale release can be switched between automatic and manual, and the count of bale shaping can be displayed.
High-density Bale With Cutting Function
The cutting system employs a down-cutting system with 10 knives. Crops can be cut to a theoretical cutting length of 9 cm, and highdensity bales can be formed.
Bottom Plate Down With a Lever
Grass clogging can be easily removed by lowering the bottom plate.
Wide Two Belt
Two wide endless belts with excellent durability are used for bale forming. Stable work can be performed for bale core making, and spills from gaps can be reduced.
Gull Wing Cover & Bale Drop Kicker
The side covers are gull-wing type, which opens and closes vertically for easy maintenance.
Input Shaft Share Bolt
Shear bolts on the input shaft prevent machine breakdown due to overloading.
Press Roller & Gauge Wheel
Press rollers allow for uniform crop uptake and smooth operation. The gauge wheel follows the unevenness of the ground, stabilizing pickup, and preventing soil contamination.
Flexible Turn V Hitch
The V-hitch 2-piece towing system allows for easy maneuvering and excellent workability. Wide pickup with a working width of 170 cm realizes smooth corner work.
※Specifications and photos are subject to change without notice for improvement.
